Production Platform 1: Highest Optical Performance Possible With the Latest Technologies
HJ14ex4.3B Series
• Widest-angle lens in the professional realm of 2/3-inch portable HD lenses
• Angular fi eld of view of 96.3º at the wide end of the 16:9 HD aspect ratio
HJ15ex8.5B KRSE-V
• First portable HD lens with built-in Canon VAP-IS Image Stabilization
• Weighs 4.4 lbs., helps maintain stable images even during jolts and vibrations
HJ17ex6.2B Series
• 6.2mm extra-wide angle of view and a built-in 2X extender
• M.O.D. of 0.4mm for close shooting in news situations
HJ17ex7.6B Series
• Cost-effective 2/3-inch HD ENG lens in a modest 3.6 lb. package
• Provides a generous wide-angle fi eld of view and advanced features
HJ18ex28B IASE A
• Provides superb image capture over very considerable distances
• Measures 10.5 inches long and weighs only 5.5 lbs.
HJ21ex7.5B Series
• Provides the widest fi eld of view among the standard telephoto series of lenses
• Innovative optical compensation reduces focus breathing to an extremely low level
HJ22ex7.6B Series
• Canon’s longest focal length portable HD lens (without an image-stabilization system)
• Lightweight (4.0 lbs.) with exceptional HD 16:9 performance
HJ40x10B IASD-V
• Range of focal length with Extender is 770mm
• Built-in image-stabilization systems for challenging telephoto assignments
HJ40x14B IASD-V
• Range of focal length with Extender is 1120mm
• Built-in image-stabilization systems for challenging telephoto assignments
Production Platform 2: Signifi cant Cost-Reduction HD Portable Lenses
KJ22ex7.6B Series
• Price-performance designed for today’s cost-effective HD camcorders
• Generous range of focal lengths, wide fi eld of view, lightweight design
KJ17ex7.7B Series
• Generous range of focal lengths, wide fi eld of view, lightweight design
• Totally re-designed Digital Drive unit
KJ10ex4.5B IRSE
• Cost-effective, high-performance HD ENG lens
• Focal lengths of up to 45mm (90mm with extender) and 93.7º wide fi eld of view
KH21ex5.7 IRSE
• For portable HD cameras with 1/2-inch imagers
• Focal lengths of up to 120mm (240mm with extender); 62.9º wide-angle view
KH16ex5.7 IRSE
• For portable HD cameras with 1/2-inch imagers
• Focal lengths of up to 91mm (182mm with extender); 62.9º wide-angle view
KH10ex3.6 IRSE
• Widest angle of view (88° horizontal) among Canon’s 1/2-inch imager lenses
• Lightweight; minimum chromatic aberrations and low geometric distortion (at widest angle)
KT17ex4.3B IRSE
• For portable HD cameras with 1/3-inch imagers
• Focal lengths of up to 73mm (146mm with extender); 62.6º wide-angle view
Production Platform 3: Lowest Cost Possible With Great HD Performance
KJ20x8.2B IRSD
• Features a built-in 2x extender, typically found in higher-end HD lenses
• Provides high performance/value for lightweight 2/3-inch image cameras
KJ20x8.5B KRSD A
• Features Canon’s cost-effective ergonomic Shuttle Shot drive unit
• Very cost-effective and lightweight HD zoom lens for 2/3-inch imager cameras
KJ13x6B KRSD
• Provides an exceptional 77.3º wide fi eld of view; weighs only 3.5 lbs.
• Focal lengths of up to 78mm; for 2/3-inch imager cameras
KH20x6.4 KRSD
• For specifi c brand/models of 1/2-inch imager HD cameras; provides wide-angle imaging
• Features Canon’s cost-effective ergonomic Shuttle Shot drive unit
KH13x4.5 KRSD
• Provides 75.7º wide fi eld of view; focal lengths of up to 59mm
• For 1/2-inch imager HD cameras; weighs only 3.5 lbs.
KH19x6.7 KAS
• For a specifi c brand of 1/2-inch imager HD cameras; wide-angle capture; only 2.8 lbs.
• Features interface to special Auto-Focus system for particular camera brand
KT20x5B KRSD
• For a specifi c brand of 1/3-inch imager HDV camcorders
• Features Canon’s cost-effective ergonomic Shuttle Shot drive unit
